G.655 Large Effective Area High Capacity Positive Dispersion Shifted Single-mode Fiber

Request a Quote

GL FIBER® provides the whole series of SMF products that meet and even excel the requirements of standards on performance indicators. Due to the high stability, these products effectively meet the demand for high speed, large capacity, long distance and small bending radius necessary for signal transmission in different applications.

optical fiber,fiber optic,652d fiber,g657a1 fiber,g657a2 fiber

Product Details

Description:

GL FIBER® fibre (Large Effective Area High Capacity Positive Dispersion Shifted Single-mode Fibre) is comprehensively optimized for attenuation and dispersion performance at the 1550 nm operating wavelength. The fibre has the lowest attenuation and moderate dispersion at 1550 nm, which enables excellent performance in multi-channel Dense Wavelength Division Multiplex (DWDM) systems traditionally operating in the C-band (1530 nm -1565 nm), as well as in emerging L-band (1565 nm -1625 nm) systems.


Application:

GL FIBER® fibre is the commercialized fibre that has the largest effective area in the G.655 series. The fibre is suitable for application of high output power Erbium Doped Fibre Amplifier (EDFA) and multi-channel Dense Wavelength Division Multiplex (DWDM), and can be effectively applied in the high bit-rate both single-and multi-channel, long distance digital transmission links even without dispersion compensation.

Feature Characteristics:

• Being applicable in the high bit-rate operation across 1530-1565 nm and 1565-1625 nm band
• Large effective area ensures good economic return from the transmission system
• Low attenuation, low dispersion, low PMD and low zero dispersion slope that satisfy the demand of transmission links
• Low bending induced loss at 1550 nm and at the moresensitive 1625 nm wavelength

Standards

GL FIBER® fibre complies with or exceeds the ITU-T G.655.C/D recommendation and IEC-60793-2-50 B4.c/d Optical Fibre Specification. GL FIBER® tightens many parameters of fibre products so as to offer more conveniences to customers.

Specifications

Characteristics

Conditions

Specified values

Units

Optical Characteristics

Attenuation

1550nm

≤0.22

[dB/km]

1625nm

≤0.24

[dB/km]

Attenuation vs. Wavelength

Max. α Difference

1525-1575nm, in reference to 1550nm

≤0.02

[dB/km]

Dispersion Coefficient

1530-1565nm

2.0-6.0

[ps/(nm·km)]

1565-1625nm

4.5-11.2

[ps/(nm·km)]

Zero Dispersion Wavelength(λ0)

--

≤1520

[nm]

Dispersion Slope

1550nm

≤0.084

[ps/(nm2·km)]

Typical dispersion slope

1550nm

0.075

[ps/(nm2·km)]

PMD

Maximum Individual Fibre

--

≤0.2

[ps/√km]

Link Design Value(M=20,Q=0.01%)

--

≤0.08

[ps/√km]

Typical Value

--

0.04

[ps/√km]

Cable Cutoff Wavelength (λCC)

--

≤1450

[nm]

Mode field diameter (MFD)

1550nm

9.1-10.1

[μm]

Effective Group Index of Refraction(Neff

1550nm

1.469

--

1625nm

1.469

--

Point Discontinuities

1550nm

≤0.05

[dB]

Geometrical Characteristics

Cladding Diameter

--

125.0±0.7

[μm]

Cladding Non-Circularity

--

≤1.0

[%]

Coating Diameter

--

235-255

[μm]

Coating-Cladding Concentricity Error

--

≤12.0

[μm]

Coating Non-Circularity

--

≤6.0

[%]

Core-Cladding Concentricity Error

--

≤0.6

[μm]

Curl(Radius)

--

≥4

[m]

Delivery Length

--

Up to 25.2

[km/reel]

Environmental Characteristics 1550nm & 1625nm

Temperature Dependence Induced Attenuation

-60℃ to +85℃

≤0.05

[dB/km]

Temperature-Humidity Cycling Induced Attenuation

-10°C to +85°C, 98% RH

≤0.05

[dB/km]

Watersoak Dependence Induced Attenuation

23°C,for 30 days

≤0.05

[dB/km]

Damp Heat Dependence Induced Attenuation

85°C , 85% RH,for 30 days

≤0.05

[dB/km]

Dry Heat Aging

85℃,30 days

≤0.05

[dB/km]

Mechanical Specifications

Proof Test

--

≥9.0

[N]

--

≥1.0

[%]

--

≥100

[kpsi]

Macro-bend Induced Attenuation

100 Turns Around a Mandrel of 30 mm Radius

1625nm

≤0.05

[dB]

100 Turns Around a Mandrel of 25 mm Radius

1550nm

≤0.05

[dB]

1 Turn Around a Mandrel of 16 mm Radius

1550nm

≤0.05

[dB]

Coating Strip Force

typical average force

1.5

[N]

peak force

1.3-8.9

[N]

Dynamic Fatigue Parameter(nd)

--

≥20

--
