Typical Designs Of Aluminum Tube OPGW

Request a Quote

Description:

The Aluminum tube is surrounded by single or double layers of aluminum clad steel wires (ACS) or mix ACS wires and aluminum alloy wires. Good anti-corrosion preformance. Material and structure are uniform, good resistance to vibration fatigue.

Cable Section:

Application:

Self-support Aerial installation

1. Good anti-corrosion performance.
2. Material and structure are uniform, good resistance to vibaration fatigue.
3. Short circuit current has small effect on the optical fiber transmission propertities.
4. Good anti-lightning performance.

There are different test series to assure the quality of GL FIBER' OPGW Cable:

∗ Routine test (in‒process testing according to internal quality plan)
∗ Factory acceptance test (FAT, witnessed by customer)
∗ Type test (only in case of a basic new design, repetition in exceptional cases)

OPGW tests shall be in accordance with applicable standards or agreements between purchaser and manufacturer. As a general rule the tests will be performed according IEC 60794-4-10.However, if necessary tests can be done according to IEEE Std1138.

OPGW Type Test

to an agreement between purchaser and manufacturer.

OPGW Routine Test

measured at 1550nm.

OPGW Factory Test

With more than 60 OPGW fiber cable designs successfully type-tested, GL FIBER has extensive experience in OPGW qualification. Additionally, our in-house laboratories certify that all cables are manufactured in compliance with the design specifications. GL FIBER' OPGW manufacturing plants are ISO 9001 and 14001 certified and the quality assurance systems are managed accordingly.

GL Fiber' Expertise Is Reflected In:

1. OEM Manufacturer: GL FIBER focus on manufacturing OPGW cable for more  than 20 years, We can OEM OPGW from 8-144 cores, Low loss ITU-T G.652.D/G.655 Fibre, Other special request also supported.

2. Quality Assurance: GL FIBER set up complete, advanced test center, with complete product test equipment and obtaining international qualification certification, controlling the quality of raw materials and finished products. Our OPGW cables products passed the type tests by authoritative institutions China Electric Power Research Institute and Shanghai Electric Cable Research Institute.

5. 7*24 Online Service: GL FIBER offer perfect pre-sales, sales, post-sales service for our customers 7*24 Online Service.

Besides, for large-scale deployment and international transportation needs, we provide flexible container packaging options - whether it is a standard 20-foot container, suitable for compact space and flexible deployment; or a spacious 40-foot container, which can meet the needs of large-scale projects. For one-stop transportation, we can accurately adapt to ensure the safe arrival of goods.
