PM Fiber

pm fiber,pmf

Small Mode Field PMF for Component

Request a Quote

Small Mode Field Polarization-Maintaining Fiber (PMF) for Components refers to a highly specialized class of single-mode optical fiber designed with a compressed Mode Field Diameter (MFD).
pm fiber,pmf

Product Details

Applications：
  • Optical spot size converter
  • Silicon photonic chip coupling
  • Polarization-sensitive components


    • Characteristics：
    • High numerical aperture (NA)
    • High birefringence
    • Excellent polishing properties
    • Low insertion loss

    Specification

    Fibre type PM 1310_125-30/250(HNA)
    Part No. PM1016-T
    Optical properties
    Operating wavelength (nm) 1310&1550
    Fibre cutoff wavelength (nm) 1100 ~ 1280
    Mode field diameter (μm) 3.4±0.4@1310nm
    Mode field diameter (μm) 4.0±0.3@1550nm
    Attenuation (dB/km) ≤50.0@1310nm
    Attenuation (dB/km) ≤30.0@1550nm
    Beat length (mm) ≤4.0@1550nm
    Typical crosstalk at 100m (dB) ≤-30@1550nm
    Typical crosstalk at 100m (dB) ≤-25@1550nm(dia.10mm, 10turns)
    Macro-bending loss (dB) ≤0.01@1550nm(dia.10mm, 10turns)
    Geometrical properties
    Coating diameter (μm) 124.5±1.0
    Cladding diameter (μm) 245.0±5.0
    Cladding non-circularity (%) ≤1.0
    Core/cladding concentricity error (μm) ≤0.5
    Structure of coating Dual-layer, UV-cured acrylate
    Mechanical performance
    Operating temperature range (°C) -45 ~ 85
    Proof test level (kpsi) 100
    Fibre length (m) Customer-specified
