ACSR/AW Aluminum Conductor Aluminum Clad Steel Reinforced

Request a Quote

Aluminum wires, concentrically stranded about an aluminum-clad steel core.
ACSR,AAAC,AAC,ACAR,ACFR Conductor

Descriptions

Aluminum wires, concentrically stranded about an aluminum-clad steel core.


Applications

Used as bare overhead transmission and as primary and secondary distribution cable.

ACSR/AW offers strength characteristics similar to ACSR, along with slightly greater ampacity and resistance to corrosion due to aluminum-cladding of the steel core wires.

Specifications

• IEC 61089 Round wire concentric lay overhead electrical stranded conductors
• ASTM B 549  Concentric-Lay-Stranded Aluminum Conductors, Aluminum-Clad Steel Reinforced for Use in Overhead Electrical Conductors
• GB/T 1179 Round wire concentric lay overhead electrical stranded conductors

Technical Parameters of ASTM B 549-ACSR/AW (1)

Code Name Conductor Size - Aluminum Aluminum Aluminum-Clad Steel Conductor Rated Strength Mass per Unit Length Nominal Outside Diameter DC Resistance  at 20°C
Number of Wires Nominal Diameter No. of Wires Nominal Diameter
MCM mm² mm mm kN kg/km mm Ω/km
Thrasher 2312 1171 76 4.43 19 2.07 246 3679 45.79 0.0244
Kiwi 2167 1098 72 4.41 7 2.94 218 3366 44.10 0.0261
Bluebird 2156 1092 84 4.07 19 2.44 262 3627 44.76 0.0259
Chukar 1780 902 84 3.70 19 2.22 220 2996 40.70 0.0314
Falcon 1590 806 54 4.36 19 2.62 236 2917 39.26 0.0346
Lapwing 1590 806 45 4.78 7 3.18 186 2598 38.22 0.0351
Parrot 1510.5 765 54 4.25 19 2.55 224 2768 38.25 0.0364
Nuthatch 1510.5 765 45 4.65 7 3.10 177 2467 37.20 0.0370
Plover 1431 725 54 4.14 19 2.48 212 2625 37.24 0.0384
Bobolink 1431 725 45 4.53 7 3.02 167 2336 36.24 0.0390
Martin 1351.5 685 54 4.02 19 2.41 201 2478 36.17 0.0407
Dipper 1351.5 685 45 4.40 7 2.93 158 2207 35.19 0.0414
Pheasant 1272 645 54 3.90 19 2.34 189 2333 35.10 0.0433
Bittern 1272 645 45 4.27 7 2.85 149 2078 34.17 0.0439
Skylark 1272 645 36 4.78 1 4.78 114 1893 33.46 0.0442
Grackle 1192.5 604 54 3.77 19 2.27 179 2188 33.97 0.0463
Bunting 1192.5 604 45 4.14 7 2.76 139 1948 33.12 0.0467
Finch 1113 564 54 3.65 19 2.19 167 2043 32.85 0.0494
Bluejay 1113 564 45 4.00 7 2.66 130 1819 31.98 0.0501
Curlew 1033.5 524 54 3.51 7 3.51 158 1896 31.59 0.0534
Ortolan 1033.5 524 45 3.85 7 2.57 121 1688 30.81 0.0540
Tanager 1033.5 524 36 4.30 1 4.30 94 1537 30.10 0.0546
Cardinal 954 483 54 3.38 7 3.38 146 1752 30.42 0.0573
Rail 954 483 45 3.70 7 2.47 113 1558 29.61 0.0585
Catbird 954 483 36 4.14 1 4.14 87 1420 28.98 0.0589
Canary 900 456 54 3.28 7 3.28 138 1653 29.52 0.0608
Ruddy 900 456 45 3.59 7 2.40 107 1470 28.74 0.0621
Mallary 795 403 30 4.14 19 2.48 165 1726 28.96 0.0668
Condor 795 403 54 3.08 7 3.08 124 1458 27.72 0.0690
Tern 795 403 45 3.38 7 2.25 96 1298 27.03 0.0701
Drake 795 403 26 4.44 7 3.45 136 1549 28.11 0.0682
Cuckoo 795 403 24 4.62 7 3.08 122 1460 27.72 0.0690

ASTM B 549-ACSR/AW (2)

Code Name Conductor Size - Aluminum Aluminum Aluminum-Clad Steel Conductor Rated Strength Mass per Unit Length Nominal Outside Diameter DC Resistance  at 20°C
Number of Wires Nominal Diameter No. of Wires Nominal Diameter
MCM mm² mm mm kN kg/km mm Ω/km
Coot 795 403 36 3.77 1 3.77 74 1183 26.39 0.0711
Redwing 715.5 363 30 3.92 19 2.35 149 1552 27.43 0.0744
Starling 715.5 363 26 4.21 7 3.28 122 1393 26.68 0.0758
Stilt 715.5 363 24 4.39 7 2.92 110 1314 26.32 0.0764
Gannet 666.6 338 26 4.07 7 3.16 116 1298 25.76 0.0812
Flamingo 666.6 338 24 4.23 7 2.82 103 1225 25.38 0.0823
Egret 636 322 30 3.70 19 2.22 133 1381 25.90 0.0836
Sooter 636 322 30 3.70 7 3.70 130 1391 25.90 0.0834
Grosbeak 636 322 26 3.97 7 3.09 110 1238 25.15 0.0853
Rook 636 322 24 4.14 7 2.76 98 1168 24.84 0.0859
Swift 636 322 36 3.38 1 3.38 61 946 23.66 0.0884
Kingbird 636 322 18 4.78 1 4.78 67 1006 23.90 0.0876
Teal 605 307 30 3.61 19 2.16 127 1314 25.24 0.0878
Wood Duck 605 307 30 3.61 7 3.61 126 1323 25.27 0.0876
Squab 605 307 26 3.87 7 3.01 105 1177 24.51 0.0898
Peacock 605 307 24 4.03 7 2.69 93 1112 24.19 0.0906
Eagle 556.5 282 30 3.46 7 3.46 119 1217 24.22 0.0954
Dove 556.5 282 26 3.72 7 2.89 97 1083 23.55 0.0972
Parakeet 556.5 282 24 3.87 7 2.58 86 1022 23.22 0.0983
Ospray 556.5 282 18 4.47 1 4.47 59 880 22.35 0.1002
Hen 477 242 30 3.20 7 3.20 104 1043 22.40 0.1115
Hawk 477 242 26 3.44 7 2.68 84 929 21.80 0.1136
Flicker 477 242 24 3.58 7 2.39 74 877 21.49 0.1148
Pelican 477 242 18 4.14 1 4.14 51 755 20.70 0.1168
Lark 397.5 201 30 2.92 7 2.92 87 869 20.44 0.1339
Ibis 397.5 201 26 3.14 7 2.44 70 774 19.88 0.1364
Brant 397.5 201 24 3.27 7 2.18 63 731 19.62 0.1377
Chickadee 397.5 201 18 3.77 1 3.77 44 628 18.85 0.1408
Oriole 336.4 170 30 2.69 7 2.69 74 737 18.83 0.1574
Linnet 336.4 170 26 2.89 7 2.25 60 655 18.31 0.1609
Merlin 336.4 170 18 3.47 1 3.47 38 531 17.35 0.1662
Ostrich 300 152 26 2.73 7 2.12 54 583 17.28 0.1804

ASTM B 549-ACSR/AW (3)

Code Name Conductor Size - Aluminum Aluminum Aluminum-Clad Steel Conductor Rated Strength Mass per Unit Length Nominal Outside Diameter DC Resistance  at 20°C
Number of Wires Nominal Diameter No. of Wires Nominal Diameter
MCM mm² mm mm kN kg/km mm Ω/km
Partridge 266.8 135 26 2.57 7 2.00 48 519 16.28 0.2035
Waxwing 266.8 135 18 3.09 1 3.09 30 421 15.45 0.2096
Penguin 211.6 107 6 4.77 1 4.77 34 412 14.31 0.2533
Cochin 211.3 107 12 3.37 7 3.37 88 710 16.85 0.2258
Brahma 203.2 103 16 2.86 19 2.48 121 894 18.12 0.2163
Dorking 190.8 96.7 12 3.20 7 3.20 81 641 16.00 0.2505
Dotterel 176.9 89.6 12 3.08 7 3.08 75 594 15.40 0.2704
Pigeon 167.8 85.0 6 4.25 1 4.25 28 326 12.75 0.3191
Guinea 159 80.6 12 2.92 7 2.92 68 534 14.60 0.3008
3/0 (5/2) 152.5 77.3 5 4.44 2 4.44 43 418 13.32 0.3261
3/0 (4/3) 141.3 71.6 4 4.78 3 4.78 63 555 14.34 0.3187
Leghom 134.6 68.2 12 2.69 7 2.69 58 452 13.45 0.3545
Quail 133.1 67.4 6 3.78 1 3.78 23 259 11.34 0.4035
2/0 (5/2) 121 61.3 5 3.95 2 3.95 36 332 11.85 0.4121
2/0 (4/3) 112.1 56.8 4 4.25 3 4.25 53 441 12.75 0.4032
Minorca 110.8 56.1 12 2.44 7 2.44 48 372 12.20 0.4308
Raven 105.6 53.5 6 3.37 1 3.37 19 205 10.11 0.5074
Petrel 101.8 51.6 12 2.34 7 2.34 44 342 11.70 0.4684
2/0 (3/4) 99.83 50.6 3 4.63 4 4.63 73 588 13.89 0.3928
1/0 (5/2) 95.91 48.6 5 3.52 2 3.52 29 263 10.56 0.5189
1/0 (4/3) 88.80 45.0 4 3.79 3 3.79 43 348 11.37 0.5070
Robin 83.69 42.4 6 3.00 1 3.00 15 162 9.00 0.6403
Grouse 80.00 40.5 8 2.54 1 4.24 22 205 9.32 0.6359
1/0 (3/4) 79.13 40.1 3 4.13 4 4.13 61 466 12.39 0.4936
1 (5/2) 76.08 38.6 5 3.13 2 3.13 24 208 9.39 0.6563
1 (4/3) 70.48 35.7 4 3.37 3 3.37 36 277 10.11 0.6413
Sparate 66.36 33.6 7 2.47 1 3.30 16 149 8.24 0.7874
Sparrow 66.36 33.6 6 2.67 1 2.67 12 129 8.01 0.8084
1/0 (2/5) 64.92 32.9 2 4.58 5 4.58 87 640 13.74 0.4730
1 (3/4) 62.77 31.8 3 3.67 4 3.67 50 369 11.01 0.6251
2 (5/2) 60.34 30.6 5 2.79 2 2.79 19 165 8.37 0.8260
2 (4/3) 55.89 28.3 4 3.00 3 3.00 29 219 9.00 0.8092

ASTM B 549-ACSR/AW (4)

Code Name Conductor Size - Aluminum Aluminum Aluminum-Clad Steel Conductor Rated Strength   Mass per Unit Length    Nominal Outside Diameter DC Resistance  at 20°C
Number of Wires Nominal Diameter No. of Wires Nominal Diameter
MCM mm²   mm   mm kN kg/km  mm Ω/km
Swallow 52.62 26.7 6 2.38 1 2.38 10 103 7.14 1.0174
1 (2/5) 51.50 26.1 2 4.08 5 4.08 73 507 12.24 0.5961
2 (3/4) 49.78 25.2 3 3.27 4 3.27 43 293 9.81 0.7874
3 (5/2) 47.85 24.3 5 2.48 2 2.48 16 131 7.44 1.0454
3 (4/3) 44.32 22.5 4 2.68 3 2.68 23 174 8.04 1.0140
Swanate 41.74 21.2 7 1.96 1 2.61 10 93 6.53 1.2511
Swan 41.74 21.2 6 2.12 1 2.12 8 81 6.36 1.2823
2 (2/5) 40.84 20.7 2 3.63 5 3.63 60 402 10.89 0.7530
3 (3/4) 39.47 20.0 3 2.91 4 2.91 34 232 8.73 0.9943
4 (5/2) 37.95 19.2 5 2.21 2 2.21 12 104 6.63 1.3164
4 (4/3) 35.15 17.8 4 2.38 3 2.38 19 138 7.14 1.2857
3 (2/5) 32.39 16.4 2 3.23 5 3.23 50 320 9.69 0.9510
4 (3/4) 31.30 15.9 3 2.60 4 2.60 27 185 7.80 1.2455
4 (2/5) 25.69 13.0 2 2.88 5 2.88 40 253 8.64 1.1962

Technical Parameters of GB/T 1179-ACSR/AW (JL/LB14) (1)

Code
Number
Steel Ratio Calculated Area Number of Wires Wire Diameter Diameter Linear Mass Rated Strength DC. Resistance at 20℃
Al. AW. Total Al AW. Al. AW. AW. Cond.
% mm² mm² mm² mm mm mm mm kg/km kN Ω/km
25/4 16.7 24.1 4.01 28.1 6 1 2.26 2.26 2.26 6.78 94.7 9.87 1.1476
40/5 16.7 38.3 6.38 44.7 6 1 2.85 2.85 2.85 8.55 150.6 15.50 0.7216
50/8 16.7 48.3 8.04 56.3 6 1 3.20 3.20 3.20 9.60 189.8 19.06 0.5724
60/10 16.7 60.4 10.1 70.5 6 1 3.58 3.58 3.58 10.7 237.6 23.15 0.4573
70/10 16.7 68.0 11.3 79.3 6 1 3.80 3.80 3.80 11.4 267.7 26.08 0.4059
70/40 58.3 69.7 40.7 110 12 7 2.72 2.72 8.16 13.6 484.2 69.21 0.3645
95/15 16.7 95.9 16.0 112 6 1 4.51 4.51 4.51 13.5 377.1 36.74 0.2882
95/55 58.3 96.5 56.3 153 12 7 3.20 3.20 9.60 16.0 670.2 93.61 0.2633
120/7 5.6 119 6.61 125 18 1 2.90 2.90 2.90 14.5 374.6 29.53 0.2391
120/70 58.3 122 71.3 193 12 7 3.60 3.60 10.8 18.0 848.2 115.0 0.2081
150/8 5.6 145 8.04 153 18 1 3.20 3.20 3.20 16.0 456.2 34.98 0.1964
150/35 23.3 147 34.4 182 30 7 2.50 2.50 7.50 17.5 653.3 74.22 0.1861
185/10 5.6 183 10.2 193 18 1 3.60 3.60 3.60 18.0 577.3 42.95 0.1552
185/30 16.3 181 29.6 211 26 7 2.98 2.32 6.96 18.9 712.9 72.55 0.1534
185/45 23.3 185 43.1 228 30 7 2.80 2.80 8.40 19.6 819.5 92.18 0.1483
200/10 5.6 198 11.0 209 18 1 3.74 3.74 3.74 18.7 623.1 46.36 0.1438
200/30 16.3 192 31.4 224 26 7 3.07 2.39 7.17 19.5 756.6 76.04 0.1445
210/10 5.6 204 11.3 215 18 1 3.80 3.80 3.80 19.0 643.3 47.86 0.1393
210/35 16.2 212 34.4 246 26 7 3.22 2.50 7.50 20.4 831.1 83.38 0.1314
210/50 23.3 209 48.8 258 30 7 2.98 2.98 8.94 20.9 928.3 104.4 0.1310
240/30 13.0 244 31.7 276 24 7 3.60 2.40 7.20 21.6 901.1 83.74 0.1146
240/40 16.3 239 38.9 278 26 7 3.42 2.66 7.98 21.7 938.5 94.26 0.1165
240/55 23.3 241 56.3 298 30 7 3.20 3.20 9.60 22.4 1070.4 117.5 0.1136
250/25 9.8 244 24.0 268 22 7 3.76 2.09 6.27 21.3 846.0 72.95 0.1154
250/40 16.3 240 39.2 279 26 7 3.43 2.67 8.01 21.7 944.4 94.90 0.1158
300/25 8.8 306 27.1 333 48 7 2.85 2.22 6.66 23.8 1040.5 90.26 0.0925
300/40 13.0 300 38.9 339 24 7 3.99 2.66 7.98 23.9 1106.9 102.9 0.0933
300/50 16.3 300 48.8 348 26 7 3.83 2.98 8.94 24.3 1177.2 116.8 0.0929
300/70 23.3 305 71.3 377 30 7 3.60 3.60 10.8 25.2 1354.7 144.3 0.0897
385/50 13.0 387 50.1 437 54 7 3.02 3.02 9.06 27.2 1429.5 133.0 0.0726
400/35 8.8 391 34.4 425 48 7 3.22 2.50 7.50 26.8 1326.6 112.9 0.0724
400/50 13.0 400 51.8 452 54 7 3.07 3.07 9.21 27.6 1477.2 137.5 0.0702
400/65 16.3 399 65.1 464 26 7 4.42 3.44 10.3 28.0 1568.1 153.6 0.0697
400/95 31.8 408 93.3 501 30 19 4.16 2.50 12.5 29.1 1797.8 196.7 0.0673

GB/T 1179-ACSR/AW (JL/LB14) (2)

Code
Number
Steel Ratio Calculated Area Number of Wires Wire Diameter Diameter Linear Mass Rated Strength DC. Resistance at 20℃
Al. AW. Total Al AW. Al. AW. AW. Cond.
% mm² mm² mm² mm mm mm mm kg/km kN Ω/km
440/30 6.9 443 30.6 474 45 7 3.54 2.36 7.08 28.3 1443.4 114.0 0.0642
435/55 13.0 437 56.6 494 54 7 3.21 3.21 9.63 28.9 1615.0 150.3 0.0642
490/35 6.9 492 34.1 526 45 7 3.73 2.49 7.47 29.9 1603.2 126.7 0.0578
485/60 13.0 485 62.8 547 54 7 3.38 3.38 10.1 30.4 1790.6 166.6 0.0579
550/40 6.9 551 38.0 589 45 7 3.95 2.63 7.89 31.6 1796.5 141.8 0.0516
620/40 6.9 620 42.8 663 45 7 4.19 2.79 8.37 33.5 2021.4 159.6 0.0458
610/75 12.7 609 77.6 687 54 19 3.79 2.28 11.4 34.1 2243.2 206.9 0.0461
630/45 6.9 623 43.1 667 45 7 4.20 2.80 8.40 33.6 2031.8 160.5 0.0456
630/55 8.8 640 56.3 696 48 7 4.12 3.20 9.60 34.3 2172.1 180.1 0.0442
700/50 6.9 697 48.2 745 45 7 4.44 2.96 8.88 35.5 2270.7 179.4 0.0408
700/85 12.7 689 87.4 776 54 19 4.03 2.42 12.1 36.3 2534.0 233.4 0.0408
720/50 6.9 725 50.1 775 45 7 4.53 3.02 9.06 36.2 2363.7 185.2 0.0392
790/35 4.3 791 34.1 825 72 7 3.74 2.49 7.47 37.4 2432.0 165.9 0.0362
785/65 8.3 785 65.4 851 84 7 3.45 3.45 10.4 38.0 2642.7 208.9 0.0362
775/100 12.7 777 98.6 875 54 19 4.28 2.57 12.9 38.5 2858.1 263.3 0.0362
800/55 6.9 814 56.3 871 45 7 4.80 3.20 9.60 38.4 2653.8 208.0 0.0349
800/70 8.8 808 71.3 879 48 7 4.63 3.60 10.8 38.6 2744.3 224.8 0.0350
800/100 12.7 795 101 896 54 19 4.33 2.60 13.0 39.0 2925.2 269.5 0.0353
880/75 8.3 884 73.6 957 84 7 3.66 3.66 11.0 40.3 2974.2 228.1 0.0321
890/115 12.7 890 113 1002 54 19 4.58 2.75 13.8 41.2 3272.7 301.5 0.0316
900/40 4.3 900 38.9 939 72 7 3.99 2.66 7.98 39.9 2768.8 188.9 0.0318
990/45 4.3 988 42.8 1031 72 7 4.18 2.79 8.37 41.8 3039.5 207.5 0.0290
1025/45 4.3 1021 44.3 1066 72 7 4.25 2.84 8.52 42.5 3142.9 214.7 0.0280
1015/85 8.3 1014 84.5 1098 84 7 3.92 3.92 11.8 43.1 3411.8 261.6 0.0280
1135/50 4.3 1135 49.2 1184 72 7 4.48 2.99 8.97 44.8 3491.4 238.4 0.0252
1100/90 8.2 1098 89.6 1188 84 19 4.08 2.45 12.3 44.9 3684.2 286.9 0.0259
1225/100 8.2 1226 100 1326 84 19 4.31 2.59 13.0 47.4 4112.3 320.4 0.0232
1270/105 8.1 1271 103 1375 84 19 4.39 2.63 13.2 48.3 4261.9 331.5 0.0223
1405/115 8.1 1408 114 1523 84 19 4.62 2.77 13.9 50.8 4721.4 367.4 0.0202

Technical Parameters of GB/T 1179-ACSR/AW (JL/LB20A) (1)

Code
Number
Steel Ratio Calculated Area Number of Wires Wire Diameter Diameter Linear Mass Rated Strength DC. Resistance at 20℃
Al. AW. Total Al AW. Al. AW. AW. Cond.
% mm² mm² mm² mm mm mm mm kg/km kN Ω/km
15/3 16.7 15.4 2.57 18.0 6 1 1.81 1.81 1.81 5.43 59.3 5.94 1.7594
25/4 16.7 24.1 4.01 28.1 6 1 2.26 2.26 2.26 6.78 92.5 9.03 1.1285
40/5 16.7 38.3 6.38 44.7 6 1 2.85 2.85 2.85 8.55 147.1 14.16 0.7096
50/8 16.7 48.3 8.04 56.3 6 1 3.20 3.20 3.20 9.60 185.4 17.61 0.5629
60/10 16.7 60.4 10.1 70.5 6 1 3.58 3.58 3.58 10.7 232.1 21.14 0.4497
70/10 16.7 68.0 11.3 79.3 6 1 3.80 3.80 3.80 11.4 261.5 23.36 0.3992
70/40 58.3 69.7 40.7 110 12 7 2.72 2.72 8.16 13.6 461.8 60.66 0.3458
95/15 16.7 95.9 16.0 112 6 1 4.51 4.51 4.51 13.5 368.3 31.79 0.2834
95/20 19.8 95.1 18.8 114 7 7 4.16 1.85 5.55 13.9 386.0 37.80 0.2831
95/55 58.3 96.5 56.3 153 12 7 3.20 3.20 9.60 16.0 639.1 83.48 0.2498
120/7 5.6 119 6.61 125 18 1 2.90 2.90 2.90 14.5 371.0 28.14 0.2378
120/20 16.3 121 19.6 140 26 7 2.43 1.89 5.67 15.4 462.9 44.67 0.2269
120/25 19.8 122 24.2 147 7 7 4.72 2.10 6.30 15.7 497.1 48.69 0.2199
120/70 58.3 122 71.3 193 12 7 3.60 3.60 10.8 18.0 808.9 100.8 0.1974
150/8 5.6 145 8.04 153 18 1 3.20 3.20 3.20 16.0 451.7 33.54 0.1953
150/20 12.9 146 18.8 164 24 7 2.78 1.85 5.55 16.7 526.5 47.34 0.1898
150/25 16.3 149 24.2 173 26 7 2.70 2.10 6.30 17.1 571.5 54.40 0.1838
150/35 23.3 147 34.4 182 30 7 2.50 2.50 7.50 17.5 634.3 67.00 0.1818
155/25 16.3 153 24.9 178 26 7 2.74 2.13 6.39 17.4 588.4 55.99 0.1785
185/10 5.6 183 10.2 193 18 1 3.60 3.60 3.60 18.0 571.7 40.92 0.1543
185/25 13.0 187 24.2 211 24 7 3.15 2.10 6.30 18.9 676.5 59.96 0.1478
185/30 16.3 181 29.6 211 26 7 2.98 2.32 7.96 18.9 696.6 66.34 0.1509
185/45 23.3 185 43.1 228 30 7 2.80 2.80 8.40 19.6 795.7 83.13 0.1449
200/10 5.6 198 11.0 209 18 1 3.74 3.74 3.74 18.7 617.1 43.72 0.1429
200/30 16.3 192 31.4 224 26 7 3.07 2.39 7.17 19.5 739.3 69.44 0.1422
210/10 5.6 204 11.3 215 18 1 3.80 3.80 3.80 19.0 637.0 45.14 0.1385
210/25 13.0 209 27.1 236 24 7 3.33 2.22 6.66 20.0 756.1 67.00 0.1322
210/35 16.2 212 34.4 246 26 7 3.22 2.50 7.50 20.4 812.1 76.17 0.1293
210/50 23.3 209 48.8 258 30 7 2.98 2.98 8.94 20.9 901.3 94.16 0.1280
240/30 13.0 244 31.7 276 24 7 3.60 2.40 7.20 21.6 883.6 77.09 0.1131
240/40 16.3 239 38.9 278 26 7 3.42 2.66 7.98 21.7 917.0 86.09 0.1146
240/55 23.3 241 56.3 298 30 7 3.20 3.20 9.60 22.4 1039.3 107.4 0.1110
250/25 9.8 244 24.0 268 22 7 3.76 2.09 6.27 21.3 832.7 67.90 0.1143
250/40 16.3 240 39.2 279 26 7 3.43 2.67 8.01 21.7 922.8 86.67 0.1139

GB/T 1179-ACSR/AW (JL/LB20A) (2)

Code
Number
Steel Ratio Calculated Area Number of Wires Wire Diameter Diameter Linear Mass Rated Strength DC. Resistance at 20℃
Al. AW. Total Al AW. Al. AW. AW. Cond.
% mm² mm² mm² mm mm mm mm kg/km kN Ω/km
300/15 5.2 297 15.3 312 42 7 3.00 1.67 5.01 23.0 921.8 68.87 0.0957
300/20 6.9 303 20.9 324 45 7 2.93 1.95 5.85 23.4 976.8 76.67 0.0931
300/25 8.8 306 27.1 333 48 7 2.85 2.22 6.66 23.8 1025.6 84.57 0.0916
300/40 13.0 300 38.9 339 24 7 3.99 2.66 7.98 23.9 1085.5 94.69 0.0921
300/50 16.3 300 48.8 348 26 7 3.83 2.98 8.94 24.3 1150.3 106.5 0.0913
300/70 23.3 305 71.3 377 30 7 3.60 3.60 10.8 25.2 1315.4 130.1 0.0877
310/20 6.9 310 21.3 331 45 7 2.96 1.97 5.91 23.7 996.9 78.25 0.0912
395/25 6.9 394 27.1 421 45 7 3.34 2.22 6.66 26.7 1268.8 97.6 0.0716
385/50 13.0 387 50.1 437 54 7 3.02 3.02 9.06 27.2 1401.8 124.0 0.0716
400/20 5.1 406 20.9 427 42 7 3.51 1.95 5.85 26.9 1261.4 90.11 0.0699
400/25 6.9 392 27.1 419 45 7 3.33 2.22 6.66 26.6 1262.3 97.2 0.0720
400/35 8.8 391 34.4 425 48 7 3.22 2.50 7.50 26.8 1307.6 105.7 0.0718
400/50 13.0 400 51.8 452 54 7 3.07 3.07 9.21 27.6 1448.6 128.1 0.0693
400/65 16.3 399 65.1 464 26 7 4.42 3.44 10.3 28.0 1532.2 140.6 0.0686
400/95 31.8 408 93.3 501 30 19 4.16 2.50 12.5 29.1 1746.1 177.2 0.0658
440/30 6.9 443 30.6 474 45 7 3.54 2.36 7.08 28.3 1426.5 107.6 0.0637
435/35 13.0 437 56.6 494 54 7 3.21 3.21 9.63 28.9 1583.7 140.1 0.0634
490/35 6.9 492 34.1 526 45 7 3.73 2.49 7.47 29.9 1584.4 119.6 0.0574
485/60 13.0 485 62.8 547 54 7 3.38 3.38 10.1 30.4 1755.9 154.1 0.0572
550/40 6.9 551 38.0 589 45 7 3.95 2.63 7.89 31.6 1775.5 133.9 0.0512
545/70 12.7 544 69.0 613 54 19 3.58 2.15 10.8 32.2 1961.6 169.7 0.0510
620/40 6.9 620 42.8 663 45 7 4.19 2.79 8.37 33.5 1997.8 150.6 0.0455
610/75 12.7 609 77.6 687 54 19 3.79 2.28 11.4 34.1 2200.2 190.6 0.0455
630/45 6.9 623 43.1 667 45 7 4.20 2.80 8.40 33.6 2008.0 151.5 0.0453
630/55 8.8 640 56.3 696 48 7 4.12 3.20 9.60 34.3 2141.0 169.9 0.0438
700/50 6.9 697 48.2 745 45 7 4.44 2.96 8.88 35.5 2244.1 169.3 0.0405
700/85 12.7 689 87.4 776 54 19 4.03 2.42 12.1 36.3 2485.6 215.1 0.0403
720/50 6.9 725 50.1 775 45 7 4.53 3.02 9.06 36.2 2337.9 176.2 0.0390
790/35 4.3 791 34.1 825 72 7 3.74 2.49 7.47 37.4 2413.2 159.1 0.0360
785/65 8.3 785 65.4 851 84 7 3.45 3.45 10.4 38.0 2606.6 196.4 0.0358
775/100 12.7 777 98.6 875 54 19 4.28 2.57 12.9 38.5 2803.4 242.6 0.0357
800/55 6.9 814 56.3 871 45 7 4.80 3.20 9.60 38.4 2622.7 197.8 0.0347
800/70 8.8 808 71.3 879 48 7 4.63 3.60 10.8 38.6 2704.9 210.5 0.0347
800/100 12.7 795 101 896 54 19 4.33 2.60 13.0 39.0 2869.3 248.3 0.0349

GB/T 1179-ACSR/AW (JL/LB20A) (3)

Code
Number
Steel Ratio Calculated Area Number of Wires Wire Diameter Diameter Linear Mass Rated Strength DC. Resistance at 20℃
Al. AW. Total Al AW. Al. AW. AW. Cond.
% mm² mm² mm² mm mm mm mm kg/km kN Ω/km
880/75 8.3 884 73.6 957 84 7 3.66 3.66 11.0 40.3 2933.5 211.3 0.0318
890/115 12.7 890 113 1002 54 19 4.58 2.75 13.8 41.2 3210.1 277.8 0.0312
900/40 4.3 900 38.9 939 72 7 3.99 2.66 7.98 39.9 2747.3 181.2 0.0317
900/75 8.3 898 74.9 973 84 7 3.69 3.69 11.1 40.6 2981.8 214.8 0.0313
990/45 4.3 988 42.8 1031 72 7 4.18 2.79 8.37 41.8 3015.9 199.0 0.0288
1025/45 4.3 1021 44.3 1066 72 7 4.25 2.84 8.52 42.5 3118.4 205.8 0.0279
1135/50 4.3 1135 49.2 1184 72 7 4.48 2.99 8.97 44.8 3464.3 228.5 0.0251
1100/90 8.2 1098 89.6 1188 84 19 4.08 2.45 12.3 44.9 3634.6 269.0 0.0256
1235/50 4.2 1239 52.2 1291 72 19 4.68 1.87 9.35 46.8 3772.0 247.7 0.0230
1225/100 8.2 1226 100 1326 84 19 4.31 2.59 13.0 47.4 4056.9 300.4 0.0230
1270/105 8.1 1271 103 1375 84 19 4.39 2.63 13.2 48.3 4204.6 310.9 0.0222
1420/60 4.2 1419 60.3 1480 72 19 5.01 2.01 10.1 50.1 4325.9 284.5 0.0201
1435/60 4.2 1436 60.3 1497 72 19 5.04 2.01 10.1 50.4 4373.1 287.1 0.0199
1405/115 8.1 1408 114 1523 84 19 4.62 2.77 13.9 50.8 4658.0 344.6 0.0200

Recommended

Whatsapp

E-mail

Wechat
