The insulators or line insulators are used in overhead transmission and distribution lines. The overhead conductors are supported on the poles or towers. In order to avoid the flow of current through supporting poles, the insulators are used to support the line conductors. We specialize in manufacturing and supplying various insulators(Porcelain/Glass/Silicone Rubber/Composite Insulators) are the commly types insulators used for T/L and S/S, With strong technical teams and advanced quality equipments and quality control system, all our products can be produced in accordance not only with the GB standard of China, but also with the international standards of BS, ASI, ANSI, IEC.


Porcelain Insulator,Glass Insulator,Silicone Rubber Insulator,Composite Insulators

Product Details

Description:

We specialize in manufacturing and supplying various insulators for Power Transmission and Overhead Lines. There are various types of insulators are used in the transmission and distribution network which are listed below:


Pin Type Insulator
Disk Type Insulator
Suspension Type Insulator
Post Insulator
Strain Insulator
Shackle Insulator (Spool)
Stay or Egg Insulator
Special Types of Insulators


Porcelain Insulators

We specialize in manufacturing and supplying various porcelain insulators, listed as below:

Solid-Core Station Post Insulators as per IEC and ANSI standards up to 500kV;
Disc Suspension Insulators as per IEC, ANSI standards from 40kN up to 300kN;
Pin Type Insulator as per BS, AS, ANSI, DIN and SA Standards up to 36kV;
Line Post Insulator as per ANSI and DIN standards;
Strain Guy Insulators;
Spool Insulators;
Shackle insulators;
Long rod suspension porcelain insulators;
Porcelain Insulator for Cutout fuses;

Wire and other Insualtors as per clients' requirements, etc.

Toughened Glass Insulators

Our Toughened Glass Insulators for 10kV to 1000kV high voltage and extra high profile trans-mission lines are listed as below:

40~550kN Standard Type Toughened Glass Insulators ;
70~300kN Anti-fog Type Toughened Glass Insulators ;
70~240kN Open Profile Type Toughened Glass Insulators;

70-100kN Ground Profile Type Toughened Glass Insulators.

Silicone Rubber Composite Insulators

We specialize in manufacturing and supplying various silicone Rubber insulators, listed as below:

Long Rod Silicone Rubber Suspension Insulator up to 500kV;
Line Post Silicone Rubber Insulators from 5kN to 12.5kN up to 36kV;
Pin Type Silicone Rubber Insulators up to 36kV;

Silicone Rubber Post Insulator up to 500kV, etc;
