GYTA53 Double Armor Double Jackets Direct Buried Fiber Cable

Request a Quote

Hunan GL Technology Co., Ltd Supply 2-144 Cores GYTA53 direct-buried fiber optic cables With Factory Price, Support OEM, All the GYTA53 cables supplied from GL FIBER are complied with IEC 60794-4、 IEC 60793、TIA/EIA 598 A standards.
UG Cables,direct-buried cable,gyta53,direct-buried fiber optic cable

Product Details

Description:

In the GYTA53 cable, single-mode/multimode fibers are positioned in the loose tubes, the tubes are filled with water blocking filling compund. Tubes and fillers are stranded around the strength member into a circular cable core. An Aluminum Polyethylene Laminate (APL) is applied around the core. Which is filled with the filling compound to protect it. Then the cable is completed with a thin PE sheath. After PSP is applied over the inner sheath, the cable is completed with a PE outer sheath.


Application:

Direct Buried


Characteristics:

The following measures are taken to ensure the water blocking performance of the cable

1. Single steel wire/FRP used as the central strength member
2. Special water-blocking filling compound in the loose tube
3. 100% cable core filling, APL and PSP moisture barrier

Standards

Comply with standard YD/T 901-2009 as well as IEC 60794-1.

Technical Parameters

Cable Type
Fiber Count Cable Diameter MM Cable Weight KG/KM

Tensile Strength

Long/Short Term N

Crush Resistance

Long/Short Term N/100MM

Bending Radius Static/Dynamic MM
GYTA53 2~12 2~12 12.5 160 1000 3000 1000 3000 10D/20D
GYTA53 14~36 14~36 12.8 165 1000 3000 1000 3000 10D/20D
GYTA53 38~72 38~72 13.4 185 1000 3000 1000 3000 10D/20D
GYTA53 74~96 74~96 14.9 220 1000 3000 1000 3000 10D/20D
GYTA53 122~144 122~144 17.4 290 1000 3000 1000 3000 10D/20D
GYTA53 146~216 146~216 17.7 300 1000 3000 1000 3000 10D/20D

Packing & Shipping

GL FIBER provides a full range of customized fiber optic cable packaging solutions carefully matching your unique needs.

Starting with customized packaging printing, your brand LOGO, safety warnings or specific information can be printed directly on the packaging carton boxes and packaging spool, which not only enhances the brand image, but also ensures the accuracy and efficiency of on-site identification.

Whether it is wooden reel that pursue natural texture and environmental protection concepts, or iron reel that emphasize sturdiness and durability, we present them all to ensure the best protection of optical cables during transportation and storage.

Besides, for large-scale deployment and international transportation needs, we provide flexible container packaging options - whether it is a standard 20-foot container, suitable for compact space and flexible deployment; or a spacious 40-foot container, which can meet the needs of large-scale projects. For one-stop transportation, we can accurately adapt to ensure the safe arrival of goods.

Cable Type Length (M) Fiber Count Outer Diameter (mm)
1000M 2000M 3000M 4000M 5000M
GYTA53 Net Weight (kg) 200 400 600 800 1000 2-60 fibers 13.6mm
Gross Weight (kg) 230 440 650 860 1060
Reel Size (cm) 80*70 100*70 120*70 130*80 140*80
Net Weight (kg) 220 440 660 880 1100 62-72 fibers 13.6mm
Gross Weight (kg) 250 480 720 950 1150
Reel Size (cm) 80*70 100*70 120*70 130*80 140*80
Above reel size is: diameter * width (cm)
