In the GYFTC8S cable, single-mode/multimode fibers are positioned in the loose tubes, while the loose tubes strand to-gether around central strength member into a compact and circular cable core, and the water-blocking materials are distributed into interstices of it. After a PSP is applied around the cable core, this part of cable accompanied with the stranded wires as the support-ting part are completed with a PE sheath to be a figure-8 structure.
Self Supporting Aerial
1. Excellent mechanical and temperature performance
2. Critical protection to fibers
Comply with standard YD/T901-2009 as well as IEC 60794-1.
Cable Type | Fiber Count | Cable Diameter MM | Cable Weight KG/KM |
Tensile Strength Long/Short Term N |
Crush Resistance Long/Short Term N/100MM |
||
GYFTC8S 2~30 | 2~30 | 9.5 ×19.1 | 160.0 | 2000 | 6000 | 300 | 1000 |
GYFTC8S 32~36 | 32~36 | 10.1 ×19.7 | 170.0 | 2000 | 6000 | 300 | 1000 |
GYFTC8S 38~60 | 38~60 | 10.8 × 20.4 | 180.0 | 2000 | 6000 | 300 | 1000 |
GYFTC8S 62~72 | 62~72 | 12.4 ×22.0 | 195.0 | 2000 | 6000 | 300 | 1000 |
GYFTC8S 74~96 | 74~96 | 13.1 × 22.7 | 222.0 | 2000 | 6000 | 300 | 1000 |
GYFTC8S 98~120 | 98~120 | 15.7 ×22.3 | 238.0 | 2000 | 6000 | 300 | 1000 |
GYFTC8S 122~144 | 122~144 | 15.5 ×25.1 | 273.0 | 2000 | 6000 | 300 | 1000 |
GL FIBER provides a full range of customized fiber optic cable packaging solutions carefully matching your unique needs.
Starting with customized packaging printing, your brand LOGO, safety warnings or specific information can be printed directly on the packaging carton boxes and packaging spool, which not only enhances the brand image, but also ensures the accuracy and efficiency of on-site identification.
Whether it is wooden reel that pursue natural texture and environmental protection concepts, or iron reel that emphasize sturdiness and durability, we present them all to ensure the best protection of optical cables during transportation and storage.
Besides, for large-scale deployment and international transportation needs, we provide flexible container packaging options - whether it is a standard 20-foot container, suitable for compact space and flexible deployment; or a spacious 40-foot container, which can meet the needs of large-scale projects. For one-stop transportation, we can accurately adapt to ensure the safe arrival of goods.
Cable Type | Length (M) | Fiber Count | Outer Diameter (mm) | |||||
1000M | 2000M | 3000M | 4000M | 5000M | ||||
GY(F)TC8S | Net Weight (kg) | 180 | 360 | 540 | 720 | 900 | 2-60 fibers | 9MMx16mm |
Gross Weight (kg) | 210 | 400 | 600 | 790 | 980 | |||
Reel Size (cm) | 80*70 | 100*70 | 120*70 | 130*70 | 140*80 |
Above reel size is: diameter * width (cm)
