GCYFY Mini Air-blown Fiber Cable

Request a Quote

Description:

The GCYFY cable structure consists of a central strengthening element, a tight-buffered optical fiber unit, an FRP (fiberglass reinforced plastic) load-bearing element and an outer PE (polyethylene) sheath. The design is strong and weather-resistant, and is suitable for self-supporting overhead deployment.

Cable Section:

Application:

1. Using microtubule resources, especially for the backbone network, access network and fiber to the home.
2. Cabling costs are low and suitable for upgrading the old city and building network.

Features:

1. Small outside diameter, light weight, easy to lay.
2. Adopt semi dry structure, construction is clean and tidy.
3. Loose tube material itself has a good water resistance and high strength.
4. Special tube filling compound ensure a critical protection of fiber.
5. Adopt the following measures to ensure the waterproof performance of the optical cable.
6. Loose tube filled with special waterproof compound.
7. Using dry type of water blocking material, the whole section of water resistance, to prevent the optical cable vertical seepage.

Fiber Count	Cable Diameter mm	Cable Weight Kg/km	Tensile Strength Long/Short Term N	Crush Resistance Long/Short Term N/100m	Bending Radius Static/Dynamic mm
2-60	5	20	1100/550	150/500	30D/15D
62-72	5.5	25	1100/550	150/500	30D/15D
74-96	6.7	32	1700/850	150/500	30D/15D

Storage/Operating Temperature : -20℃ to + 70℃

GL provides a full range of customized fiber optic cable packaging solutions carefully matching your unique needs.

Starting with customized packaging printing, your brand LOGO, safety warnings or specific information can be printed directly on the packaging carton boxes and packaging spool, which not only enhances the brand image, but also ensures the accuracy and efficiency of on-site identification.

Whether it is wooden reel that pursue natural texture and environmental protection concepts, or iron reel that emphasize sturdiness and durability, we present them all to ensure the best protection of optical cables during transportation and storage.

Besides, for large-scale deployment and international transportation needs, we provide flexible container packaging options - whether it is a standard 20-foot container, suitable for compact space and flexible deployment; or a spacious 40-foot container, which can meet the needs of large-scale projects. For one-stop transportation, we can accurately adapt to ensure the safe arrival of goods.
