Aerial ADSS Multi-Tube (MT) Fiber Glass Yarns

Date:2024-07-27

Aerial ADSS Multi-Tube (MT) Fiber Glass Yarns, The most cost-effective solution for use on short and medium spans. It will have a smaller diameter and be lighter compared to a double jacket design. The fiberglass yarn provides a degree of rodent resistance.

Features:

Maximum reted design tension up to2248 lb with span lengths up to 656 ft

Reduced weight and size

Low susceptiblity to ice and wind loads

Cost-effective solution for city trunk lines

Aerial installation on distribution and teansmission lines up to 34.5kv

All dielectric design

Wide range of operating temperatures, Installation temperature down to -22°F

Optical Fiber Specifications

Maximum rated design tension, lb	450
Crush	126 lb/in (0.22 kN/cm)
Fiber count, up to	72 (6х12)	96 (8х12)	144 (12х12)
Cable diameter, in	0.354	0.406	0.516
Cable weight, lb/ft	0.042	0.053	0.087
Minimum bending radius, in	5.3	6.1	7.7

Maximum rated design tension, lb	674
Crush	126 lb/in (0.22 kN/cm)
Fiber count, up to	72 (6х12)	96 (8х12)	144 (12х12)
Cable diameter, in	0.39	0.441	0.539
Cable weight, lb/ft	0.051	0.064	0.095
Minimum bending radius, in	5.8	6.6	8.1

Maximum rated design tension, lb	899
Crush	126 lb/in (0.22 kN/cm)
Fiber count, up to	72 (6х12)	96 (8х12)	144 (12х12)
Cable diameter, in	0.461	0.539	0.677
Cable weight, lb/ft	0.07	0.092	0.145
Minimum bending radius, in	6.9	8.1	10.2

Maximum rated design tension, lb	1349
Crush	126 lb/in (0.22 kN/cm)
Fiber count, up to	72 (6х12)	96 (8х12)	144 (12х12)
Cable diameter, in	0.469	0.539	0.677
Cable weight, lb/ft	0.073	0.095	0.145
Minimum bending radius, in	7	8.2	10.2

Maximum rated design tension, lb	1798
Crush	126 lb/in (0.22 kN/cm)
Fiber count, up to	72 (6х12)	96 (8х12)	144 (12х12)
Cable diameter, in	0.48	0.555	0.685
Cable weight, lb/ft	0.079	0.1	0.15
Minimum bending radius, in	7.2	8.3	10.3

Maximum rated design tension, lb	2248
Crush	126 lb/in (0.22 kN/cm)
Fiber count, up to	72 (6х12)	96 (8х12)	144 (12х12)
Cable diameter, in	0.496	0.567	0.697
Cable weight, lb/ft	0.086	0.106	0.156
Minimum bending radius, in	7.4	8.5	10.5
