Why Choose GL Fiber' ADSS Cable Accessories?

GL Fiber ADSS cable accessories are suitable for installation of Aerial Optical Fiber Cable between pole to pole, pole to the building of internet.

GL FIBER' ADSS accessories are designed to be self-damping so as to prevent low amplitude, high-frequency vibration.

GL FIBER' ADSS accessories which include dead end cable grip, preformed suspension clamp are never allowed the transfer of tensile load more than 95% of the maximum permissible tensile load of ADSS cable.

Slippage will only happen between a protective helical rod and terminal helical rod. The protective helical rod will not slip.

The quality control process ensures that the products meet all the specification requirements for lifetime using. Our quality management systems performance ISO9001:2015 requirements.

The QC team has a quality plan which is confirmed and acceptable by certain customers. The quality plan includes quantity for each month, gripping test, tension testing, packing.

The Qc team will support and execute the customer inspection ways, at the same time, GL QC team has to know the procedures, work instructions, inspection, and test results.

The QC team will forward the documents to show what they have done accordingly. All the documents will be reviewed and approved by the final customer.

The Material of ADSS Cable Accessories

GL FIBER' ADSS cable accessories that are lashed to messenger wire are made from galvanized steel wire, aluminum alloys wire, aluminum-clad steel wire. The steel wire used for a helical rod will be a galvanizing coating of 275g/m2 or 43miron.

For any other components, the galvanizing coating mass is according to ISO1461 or applicable material standard unless specified otherwise.

GL FIBER' chooses the raw material according to non-toxic and dermatologically safe.

GL FIBER' key products in ADSS Cable Accessories

1.Preformed Armour Rod

GL FIBER' preformed armour rod, which also called structural reinforcing rod(SRR) is made of galvanized high tensile steel wire or aluminum alloy wire. The helical rods will be glued together to form a line. Three or four lines consist of one set of preformed armour rod.

GL FIBER' preformed armour rods were installed directly on the ADSS Optical Fiber before assembling the preformed dead-end grips and performed suspension clamp.

GL FIBER' preformed armour rod will spread the radial force of the preformed tension/suspension clamp with a longer zone of contact, in this way, Our preformed armour rod will reduce the locally concentrated high pressure of these pointed loads.

By increasing the total area of contact with the cable, Our Preformed armour rod can reduce the torsional deformation in the part of contact between the cable and the fixture.

Once the diameter, length, and number of wires in one subset and number of subsets in one set of preformed armour rod confirmed, the basic specification was confirmed

2.Dead End Cable Grips

GL FIBER' dead end cable grips are made of hot-dip galvanized high tensile steel wires or aluminum alloy which are laid side by side and glued together and bent to form a loop.

The loop was used to hold a thimble. Our dead end cable grips are designed to reduce the torsional deformation in the part of contact between the cable and the helical part by increasing the total area of the contact.

GL FIBER' dead end cable grips are attached effectively to the cable and distribute the radially compressive forces over a wide area while providing excellent grip to the cable without undue stress on the fiber.

3.Preformed suspension clamp

GL FIBER' preformed suspension clamp which also calls suspension helix has a different shape with dead-end cable grip. Our suspension helix is bent to form a loop in the middle which is fitted with a steel ring or a clevis thimble.

The Preformed suspension clamp specification is designed the same way as the preformed armour rod.

4.Vibration Damper

GL FIBER' spiral vibration damper is made of a solid PVC rod and designed in the form of a spiral to suit the cable diameter.

GL FIBER' spiral dampers have two sections: gripping and dampening section. The gripping section was wound over the protective helix and the dampening section was wound loosely over the cable.
